3528RGB

· 3.5 mm × 2.8 mm
· PCT material
· 3-channel adjustable RGB
· Covers low-to-medium power applications
· RoHS, REACH certification
· LM-80, UL certification

Red

Power (W)	Vavelength (nm)	Color	Forward Cuttent (mA)	Forward Voltage (V)	Luminous Flus (lm)	Size (mm)
0.2	618-623	Red	20	2.0	3.6	3.5×2.8
	519-523	Green	20	3.0	6.6	3.5×2.8
	464-469	Blue	20	3.0	1.5	3.5×2.8

RGB
